Yamaha Ray Z 113
NRs. 2,00,900
Key Specifications
Engine Displacement (CC)
159.7 cc
Fuel Type - M
Petrol
No Of Gears
5 Speed
Mileage (ARAI) kmpl - M
60 Kmpl
Engine
Engine Type M
Air-Cooled, 4-Stroke, SOHC, 2-Valve Single Cylinder
Engine Displacement (CC)
113 cc
Power (PS@rpm)
7.1 PS @ 7500 rpm
Torque (Nm@rpm)
8.1 Nm @ 5000 rpm
Bore
50 mm
Stroke
57.8 mm
Drive Type - M
V-belt automatic
Valves (per cylinder)
2
Fuel System
Carburetor
Ignition
CDI(Capacitor Discharge lgnition)
Fuel Type - M
Petrol
Transmission
No Of Gears
V-Belt Automatic
Brakes
Brakes Front - M
Drum
Brakes Rear- M
Drum
Performance and Fuel economy
Mileage (ARAI) kmpl - M
66 Kmpl
0-60 (km/h)
12
Top Speed (Km/h) - M
86 Kmph
Chassis and Suspension
Chassis Type
Underbone
Suspension-Front
Telescopic
Suspension-Rear
Unit swing
Tyres and Wheels
Tyre Size (Front)
90/100 - 10
Tyre Size (Rear)
90/100 - 10
Wheel Size- M
Front :-10 inch Rear :-10 inch
Tyre Type - M
Tubeless
Wheels Type (Pressed Steel/ Alloy)
Alloy
Dimensions
Length*Width*Height
1835*675*1090
Wheelbase(mm)
1270 mm
Ground Clearance (mm)
128 mm
Fuel Capacity (Litres)
5.2 Ltrs
Kerb Weight - M
104 Kg
Electricals
Battery
12 V - 5 Ah (10 H)
Head Lamp
12V 35/35W XI, Halogen Bulb
Warranty
Standard Warranty (Years)
2
Standard Warranty (kilometers)
30000
