MediaTek Launches Dimensity 7200 Processor: Midrange Chip Based on 2nd Gen TSMC 4nm Process

February 19th 2023

3 mins read

MediaTek Launches Dimensity 7200 Processor: Midrange Chip Based on 2nd Gen TSMC 4nm Process

MediaTek has announced the new Dimensity 7200 processor, starting its new Dimensity 7000 series. The Dimensity 7200 brings TSMC 4nm process, cutting-edge AI imaging features, powerful gaming optimizations, and impressive 5G speeds for future mid-range phones. So, let’s check out the capabilities of this new MediaTek SoC by going through its specs and features.

MediaTek Dimensity 7200 Overview

MediaTek Dimensity 7200 is built using the same TSMC 4nm second-generation process found in the Dimensity 9200, MediaTek’s most powerful chip. This octa-core processor features 2nd generation Armv9 processors with a fast peak performance of up to 2.8GHz. This includes two Arm Cortex-A715 cores and six Cortex-A510 cores.

This new MediaTek chip features the Arm Mali G610 MC4 GPU that supports fast response times and high frame rates. Besides, you get MediaTek HyperEngine 5.0, which provides gaming-related optimizations to the phone. It delivers optimized 5G and Wi-Fi game connections, exclusive AI-VRS for power savings, CPU & GPU smart resource optimization, and more.

In short, the Dimensity 7200 will deliver effortless multitasking and gaming performance while maximizing battery life.

The MediaTek Dimensity 7200 also features a built-in MediaTek APU 650 to maximize the efficiency of AI tasks and AI fusion. For optics, MediaTek’s Imagiq 765 premium-grade 14-bit HDR-ISP supports 200MP main cameras. Adding on, the chip also supports 4K HDR video recording or dual 1080P video capture while using all-pixel autofocus.

Other capabilities of the Dimensity 7200 include support for global HDR standards like HDR10+, CUVA HDR, and Dolby HDR for media streaming and playback. The chip further integrates a 3GPP Release-16 standard Sub-6GHz 5G modem with up to 4.7Gbps downlink and supports triband Wi-Fi 6E connectivity and next-gen Bluetooth 5.3. Moreover, the full MediaTek Dimensity 7200 specs are in the table below:

MediaTek Dimensity 7200 Specifications

Processor
CPU	2x Arm Cortex-A715 up to 2.8GHz 6x Arm Cortex-A510
Cores	Octa (8)
Graphics
GPU Type	Arm Mali-G610 MC4
Video Encoding	H.264 HEVC
Video Playback	H.264 HEVC VP-9
AI	MediaTek 5th generation APU 650
Memory and Storage
Memory Type & Frequency	LPDDR4x LPDDR5
Max Memory Size	Up to 6400Mbps
Storage Type	UFS 3.1
Connectivity
Cellular Technologies	2G-5G Multi-Mode, 5G/4G CA, 5G/4G FDD / TDD, CDMA2000 1x/EVDO Rev. A (SRLTE), EDGE, GSM, TD-SCDMA, WDCDMA
Specific Functions	SA & NSA modes; SA Option2, NSA Option3 / 3a / 3x, NR TDD and FDD bands, DSS, NR DL 2CC 200MHz bandwidth, 4x4 MIMO, 256QAM NR UL 2CC, R16 UL Enhancement, 2x2 MIMO, 256QAM VoNR / EPS fallback
Peak Download Speed	4.7Gbps
GNSS	GPS BeiDou Glonass Galileo QZSS
Others	Wi-Fi 6E (a/b/g/n/ac/ax), Bluetooth 5.3
Camera
Max Camera Sensors	200MP
Max Video Capture Resolution	4K30 (3840 x 2160)
Camera Features	Video HDR Video EIS Dual simultaneous video capture AI-2A (AI-AF, AI-AWB) All-pixel AF
Display
Max Refresh Rate	Full HD+ @ 144Hz

Conclusion

With the Dimensity 7200, MediaTek has started its new Dimensity 7000 series for the upcoming mid-range phones. The chip delivers the same TSMC 4nm second-generation process found in the flagship Dimensity 9200. Moreover, the company states that the Dimensity 7200 will be great for gaming and photography without hampering battery efficiency.
